Ubiquiti Networks 900 MHz YAGI Antenna 2-Pack – AMY-9M16 High Gain Wireless Antenna
$156.75
Boost your wireless network range with Ubiquiti Networks AMY-9M16 900 MHz YAGI Antenna 2-Pack, featuring 16 dBi gain and durable weather-resistant design.
In stock
Description
Enhance your wireless data network’s coverage with the Ubiquiti Networks AMY-9M16 900 MHz YAGI Antenna 2-Pack. Operating within the 902-928 MHz frequency range, this antenna offers a high 16 dBi gain in dual linear polarizations, allowing it to direct the wireless signal in two directions for improved connectivity. Built to withstand harsh weather, it features an outdoor UV stabilized plastic enclosure and a pole mounting kit designed to resist winds of up to 120 mph. The antenna is backed by a 400 MHz Atheros MIPS 24KC processor, 64MB SDRAM, and 8MB Flash memory, ensuring reliable and smooth operation.
Additional information
| Weight | 18.35 lbs |
|---|---|
| Dimensions | 67 × 13 × 12 in |
| Processor | 400 MHz Atheros MIPS 24KC |
| Frequency Range | 902 – 928 MHz |
| ETSI Specification | EN 302 326 DN2 |
| Cross-pol Isolation | 20 dB |
| Polarization | Dual linear |
| Wind Loading | 35 ft-lbs @ 100 mph |
| Wind Survivability | 120 mph |
| Max VSWR | |
| F/B Ratio | 20 dB |
| Vpol Beamwidth | 29 to 34° |
| Hpol Beamwidth | 29 to 34° |
| Gain | 16 dBi, both polarizations |
| Shock and Vibration | ETSI300-019-1.4 |
| Memory | 64 MB SDRAM, 8MB Flash |
| Operating Humidity | 5 to 95% |
| Operating Temperature | -22 to 158°F / -30 to 70°C |
| Power Method | Passive Power over Ethernet (pairs 4, 5+; 7, 8 return) |
| Power Supply | 24 V, 1 A PoE supply included |
| Max Power Consumption | 6.5 W |
| Mounting Kit | Pole mounting kit included |
| Enclosure Characteristics | Outdoor UV stabilized plastic |
| RoHS Compliance | Yes |
| Wireless Approvals | FCC Part 15.247, IC RS210 |
| Networking Interface | 1 x 10/100 Ethernet port |
| Mounting | M8 U-Bolt pole mounting kit included |
