Optimize your network to better support high-speed remote VPN configurations for enhanced remote work performance with the QHora-301W AX3600 Wireless Dual-Band 10Gb / Gigabit SD-WAN Router from QNAP. In addition to having two 10GbE WAN/LAN ports, four Gigabit Ethernet ports, and support for 802.11ax Wi-Fi, the QHora-301W allows you to take advantage of QNAP’s Software-Defined Wide Area Network (SD-WAN) technology, QuWAN, to establish a secure mesh VPN with devices at multiple sites. With SD-WAN, you can efficiently expand remote working and distributed workforce operations without having to use additional enterprise-grade VPN equipment. It uses software-defined networking to automatically deploy connected WAN services and VPN sites to achieve optimal network bandwidth and transmission speeds, thereby overcoming the bandwidth bottlenecks that can occur with a traditional headquarters-centered network infrastructure.
| Weight | 4.26 lbs |
|---|---|
| Dimensions | 12.85 × 11.55 × 2.95 in |
| Wireless Frequency Bands | 2.4 GHz, 5 GHz Dual-Band |
| VPN Support | L2TP, Pass-Through |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Power Consumption | 24 W |
| DC Input Power | 12 VDC |
| Supported IEEE Standards | 802.11ac, 802.11ax, 802.11a, 802.11b, 802.11g, 802.11n |
| Processor | 2.2 GHz Qualcomm IPQ8072A Hawkeye 2 Quad-Core |
| Storage Capacity | 4 GB |
| Firewall Support | NAT |
| Guest Network Support | Yes |
| Number of Antennas | 8 |
| Throughput | 3657 Mb/s Total <br>5 GHz: 2475 Mb/s <br>2.4 GHz: 1182 Mb/s |
| USB Sharing Support | Yes |
| Ports | 2 x 10Gb Ethernet (RJ45)<br />4 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45)<br />2 x 5 Gb/s USB Type-A |
| Antenna Placement | Internal |
| Supported Protocols | IPv4<br>Link Aggregation |
| Antenna Gain | 4.5 to 5.2 dBi |
| WLAN Mode | Wi-Fi 6 (802.11ax) |
| MU-MIMO Support | 4 x 4 |
| Operating Humidity | 5 to 95% |
