ASUS Prime Z590M-PLUS LGA 1200 Micro-ATX Motherboard for Intel 10th & 11th Gen CPUs
$131.24
High-performance ASUS Prime Z590M-PLUS motherboard for gaming and business, supporting Intel 10th and 11th gen processors, PCIe 4.0, and up to 128GB DDR4 RAM.
In stock
Description
Elevate your PC build with the ASUS Prime Z590M-PLUS LGA 1200 Micro-ATX Motherboard, designed for both style and high-performance computing. This motherboard supports Intel 10th and 11th gen processors, ensuring compatibility with the latest CPUs. With PCIe 4.0 integration for faster graphics cards and M.2 SSDs when paired with 11th Gen Intel CPUs, it offers enhanced data transfer speeds. It accommodates up to 128GB of DDR4 RAM at speeds up to 5133 MHz (O.C.), making multitasking seamless. ASUS’s OptiMem II technology further enhances memory stability and reduces latency, optimizing overall system performance for both gaming enthusiasts and business professionals.
Additional information
| Weight | 2.82 lbs |
|---|---|
| Dimensions | 10.9 × 10.5 × 2.7 in |
| Chipset | Intel Z590 |
| Expansion Slots | 1 x PCIe 4.0 x16 (x16 mode)<br />1 x PCIe 3.0 x16 (x4 mode)<br />2 x PCIe 3.0 x1 |
| Supported Operating Systems | Windows 10 (64-Bit) |
| Audio Codec | Realtek ALC897 (7.1-Channel) |
| I/O Connection Headers | USB 3.1 / USB 3.2 Gen 1 |
| ROM | 192 Mb |
| Legacy | 1 x Serial |
| Add-On | 1 x Thunderbolt Card Header |
| Diagnostics | Clear CMOS |
| LED Header | 4 x RGB |
| Security | Chassis Intrusion, TPM Module |
| Power Connectors | 1 x 24-Pin Mainboard<br />1 x 8-Pin ATX<br />1 x 4-Pin ATX |
| Liquid Cooling | 1 x 4-Pin Pump |
| Air Cooling | 2 x 4-Pin CPU<br />2 x 4-Pin System |
| Optane Memory Support | Yes |
| CPU Socket | LGA 1200 |
| U.2 | None |
| M.2 | 1 x M Key 2242, 2260, 2280 (PCIe 4.0 x4)<br />1 x M Key 2242, 2260, 2280 (PCIe 3.0 x4, SATA III)<br />1 x M Key 2260, 2280 (PCIe 3.0 x4) |
| SATA | 5 x SATA III |
| ECC Support | Non-ECC Unbuffered |
| Channel Architecture | Dual Channel |
| Maximum Capacity | 128 GB |
| Memory Support | DDR4 2133, 2400, 2666, 2800, 2933, 3000, 3200, 3333, 3400, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4500, 4600, 4700, 4800, 5000, 5133 MHz |
| Memory Slots | 4 x 288-Pin |
| Ethernet / Controller | 1 x Intel I219V Gigabit |
| Display | 1 x DisplayPort 1.4<br />1 x DVI-D <br />1 x HDMI 2.0 |
| Thunderbolt | None |
| USB | 2 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 4 USB Type-A Port)<br />2 x USB 2.0 Header (Supports 3 USB Type-A Port) |
| Form Factor | Micro-ATX |
