The black Honeywell Genesis Cat 6 Unshielded Twisted Pair Plenum Communication Cable is a 1000′ long cable that comes in a reel-in-a-box and is rated by UL and has #23 AWG solid bare copper conductors. It features FEP insulation, no spacer, a PVC jacket with ripcord under jacket and sequential footage markings. It is ETL Verified to TIA/EIA-568-B.2-1 requirements and sweep tested to 350 MHz.
| Weight | 26.6 lbs |
|---|---|
| Dimensions | 12.5 × 12.2 × 10.4 in |
| Type | 23/4PR Cat 6 CMP |
| Voltage Rating | 300V |
| Current | 1.4A |
| DC Resistance | Nominal: 7.6 ohms/100m<br> Maximum: 9.38 ohms/100m |
| Resistance | Unbalance:<br> Nominal: 1.5%<br> Maximum: 5% |
| Capacitance | Nominal: 4.9 nF/100m<br> Maximum: 5.6 nF/100m<br> Unbalance: Nominal: 50 pF/100m<br> Maximum: 330 pF/100m |
| Velocity of Propagation | Nominal: 69% |
| Propagation Delay | Nominal: 535 ns/100m<br> Maximum: 570 ns/100m |
| Delay Skew (ns/100 m) | Nominal: 20 ns/100m<br> Maximum: 45 ns/100m |
| Cable Diameter | 0.2" / 0.5 cm |
| Insulation | FEP |
| Jacket | PVC jacket |
| Minimum Bend Radius | 1" / 2.54 cm |
| Pull Strength | 25 lbs / 11.33 kg |
| Cable Length | 1000' / 304.8 m |
