Description
Honeywell Genesis Cat 6 Plenum Cable – 1000ft Blue
The Honeywell Genesis Cat 6 Unshielded Twisted Pair Plenum Communication Cable is designed for high-performance networking needs. This 1000ft blue cable comes in a convenient reel-in-a-box packaging, making it easy to manage and deploy in various environments.
Key Features:
- 1000ft length, ideal for extensive network installations
- #23 AWG solid bare copper conductors for reliable data transmission
- FEP insulation and fluoropolymer spacer for enhanced signal integrity
- LSPVC jacket with ripcord for easy installation
- ETL Verified to TIA/EIA 568-B.2-1 requirements for quality assurance
- Sequential footage markings for accurate length measurement
This Cat 6 plenum cable is perfect for commercial and industrial applications where high-speed data transmission is crucial. The unshielded twisted pair design minimizes crosstalk and ensures reliable connectivity. With its UL rating and ETL verification, this cable meets stringent safety and performance standards.
The Honeywell Genesis Cat 6 cable is designed to support high-bandwidth applications, including Gigabit Ethernet and other high-speed networking protocols. Its durable construction and plenum rating make it suitable for use in air-handling spaces, ensuring compliance with local building codes.
Upgrade your network infrastructure with the Honeywell Genesis Cat 6 Unshielded Twisted Pair Plenum Communication Cable. Its high-quality construction, reliable performance, and compliance with industry standards make it an excellent choice for businesses and organizations seeking to establish a robust and efficient network.
Additional information
| Weight | 34.4 lbs |
|---|---|
| Dimensions | 14.4 × 13.6 × 13.5 in |
| Type | 23/4PR Cat 6 CMP |
| Voltage Rating | 300V |
| Current | 1.4A |
| DC Resistance | Nominal: 7.6 ohms/100m<br> Maximum: 9.38 ohms/100m |
| Resistance | Unbalance:<br> Nominal: 1.5%<br> Maximum: 5% |
| Capacitance | Nominal: 4.9 nF/100m<br> Maximum: 5.6 nF/100m<br> Unbalance: Nominal: 50 pF/100m<br> Maximum: 330 pF/100m |
| Velocity of Propagation | Nominal: 70% |
| Propagation Delay | Nominal: 515 ns/100m<br> Maximum: 570 ns/100m |
| Delay Skew (ns/100 m) | Nominal: 17 ns/100m<br> Maximum: 45 ns/100m |
| Cable Diameter | 0.24" (0.6 cm) |
| Insulation | 100% FEP |
| Jacket | 23 Solid Bare Copper |
| Minimum Bend Radius | 1" / 2.54 cm |
| Pull Strength | 25 lbs / 11.33 kg |
| Cable Length | 1000' / 304.8 m |
