Description
Honeywell Genesis Category 5e Unshielded Twisted Pair Plenum Communication Cable
Experience high-speed and reliable data transmission with the Honeywell Genesis Category 5e Unshielded Twisted Pair Plenum Communication Cable. This 1000-foot yellow cable is designed for efficient data transfer and comes in a convenient pull box for easy installation.
Key Features:
- UL rated for safety and performance
- #24 AWG solid bare copper conductors for optimal signal transmission
- 100% FEP insulation for durability and signal integrity
- LSPVC jacket with a ripcord for easy stripping
- Sequential footage markings for accurate installation
- ETL Verified to TIA/EIA 568-C Category 5e standards
This cable is ideal for commercial and industrial applications where high-quality data transmission is critical. The Category 5e rating ensures that it can handle data transfer rates of up to 1 Gigabit Ethernet, making it perfect for modern networking needs.
Benefits:
- Reliable and fast data transmission
- Durable construction for long-lasting performance
- Easy to install with a ripcord and sequential footage markings
- Meets or exceeds industry standards for quality and performance
Upgrade your network infrastructure with the Honeywell Genesis Category 5e Unshielded Twisted Pair Plenum Communication Cable. Its high-quality construction and reliable performance make it an excellent choice for any data communication needs.
Additional information
| Weight | 21.55 lbs |
|---|---|
| Dimensions | 14.33 × 12.91 × 10.39 in |
| Type | 24/4PR CAT5e CMP |
| Voltage Rating | 300V |
| Current | 1.4A |
| DC Resistance | Nominal: 7.6 ohms/100m<br> Maximum: 9.38 ohms/100m |
| Resistance | Unbalance:<br> Nominal: 1.5%<br> Maximum: 5% |
| Capacitance | Nominal: 4.9 nF/100m<br> Maximum: 5.6 nF/100m<br> Unbalance: Nominal: 50 pF/100m<br> Maximum: 330 pF/100m |
| Velocity of Propagation | Nominal: 71% |
| Propagation Delay | Nominal: 505 ns/100m<br> Maximum: 570 ns/100m |
| Delay Skew (ns/100 m) | Nominal: 15 ns/100m<br> Maximum: 45 ns/100m |
| Cable Diameter | 0.2" (0.5 cm) |
| Insulation | 100% FEP |
| Jacket | 24 Solid Bare Copper |
| Minimum Bend Radius | 0.8" (2.03 cm) |
| Pull Strength | 25 lbs (11.33 kg) |
| Cable Length | 1000' (304.8 m) |
