GIGABYTE Gigabyte Z590 AORUS MASTER LGA 1200 ATX Motherboard for 11th Gen Intel Processors
$261.29
High-performance ATX motherboard featuring LGA 1200 socket, DDR4 RAM, PCIe 4.0, Wi-Fi 6, and 10GbE LAN for gaming and heavy applications
In stock
Description
Unlock the full potential of your Intel 11th Gen processor with the GIGABYTE Z590 AORUS MASTER LGA 1200 ATX Motherboard. This motherboard is designed for gamers and builders seeking high-performance capabilities. The LGA 1200 socket supports a range of Intel processors, while four dual-channel DDR4 RAM slots support up to 5400 MHz for seamless multitasking.
With six SATA III and three M.2 storage interfaces, you can easily install PCIe 3.0 and 4.0 NVMe SSDs for enhanced storage and system performance. The Z590 AORUS MASTER also features two PCIe 4.0 x16 and one PCIe 3.0 x16 slots for flexible graphics and utility card configurations. USB 3.2 Gen 1, Gen 2, and Gen 2×2 ports provide fast data transfer for external devices. Enjoy fast wireless connectivity with Wi-Fi 6 (802.11ax) or opt for a stable 10GbE RJ-45 LAN connection for competitive gaming. Customize your build with addressable RGB headers for a unique aesthetic.
Additional information
| Weight | 5.86 lbs |
|---|---|
| Dimensions | 13.7 × 11.7 × 3.3 in |
| Chipset | Intel Z590 |
| Expansion Slots | 1 x PCIe 4.0 x16<br />1 x PCIe 4.0 x16 (x8 mode)<br />1 x PCIe 3.0 x16 (x4 mode) |
| Supported Operating Systems | Windows 10 (64-Bit) |
| Wi-Fi | Wi-Fi 6 (802.11ax) (MU-MIMO) |
| Bluetooth | 5.2 |
| Audio Codec | Realtek ALC1220-VB (7.1-Channel) |
| I/O Connection Headers | USB 3.1 / USB 3.2 Gen 1, USB 3.1 / USB 3.2 Gen 2 |
| ROM | 256 Mb |
| Add-On | 2 x Thunderbolt Card Header |
| Diagnostics | BIOS Selection, Clear CMOS, Power, Reset |
| LED Header | 4 x RGB |
| Security | TPM Module |
| Power Connectors | 1 x 24-Pin Mainboard<br />1 x 8-Pin ATX |
| Liquid Cooling | 1 x 4-Pin Pump |
| Air Cooling | 1 x 4-Pin CPU<br />8 x 4-Pin System<br />2 x Thermal Sensor<br />1 x Noise Sensor |
| Multi-GPU Support | 2-Way, Quad-GPU AMD CrossFireX |
| RAID Support | RAID 0, 1, 5, 10 |
| CPU Socket | LGA 1200 |
| Memory Slots | 4 x 288-Pin |
| USB | 1 x USB 3.1 / USB 3.2 Gen 2 Header (Supports 1 USB Type-C Port)<br />2 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 4 USB Type-A Port)<br />2 x USB 2.0 Header (Supports 4 USB Type-A Port) |
| Thunderbolt | None |
| Display | 1 x DisplayPort |
| Ethernet / Controller | 1 x Aquantia 10GbE |
| Wi-Fi Antenna | 2 x Connector |
| Buttons | BIOS Flashback, Clear CMOS |
| Memory Support | DDR4 2133, 2400, 2666, 2800, 2933, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3666, 3733, 3800, 3866, 4000, 4133, 4266, 4300, 4400, 4500, 4600, 4700, 4800, 4933, 5000, 5133, 5333, 5400 MHz |
| Optane Memory Support | Yes |
| Maximum Capacity | 128 GB |
| Channel Architecture | Dual Channel |
| ECC Support | Non-ECC, ECC Unbuffered |
| SATA | 6 x SATA III |
| M.2 | 1 x M Key 2242, 2260, 2280, 22110 (PCIe 4.0 x4, PCIe 4.0 x2, PCIe 3.0 x4, PCIe 3.0 x2)<br />2 x M Key 2242, 2260, 2280, 22110 (PCIe 3.0 x4, PCIe 3.0 x2) |
| U.2 | None |
| Form Factor | ATX |
