Covering 100% of the sRGB color space and supporting the Rec. 709 standard, the BL2420PT 24″ 16:9 CAD/CAM IPS Monitor from BenQ is designed to be used for a variety of tasks such as graphic design, photo editing, and animation. The BL2420PT even comes equipped with a CAD/CAM mode supporting high color contrast for use with 3D color lines. To switch between the various viewing modes, BenQ has included an OSD controller built right into the monitor, making it easy to switch between CAD/CAM, animation, and low blue light modes as well as the ability to customize controller settings with the click of a button. In addition to low blue light mode, this monitor features ZeroFlicker which virtually eliminates all flicker from the display to reduce eye fatigue during periods of extended viewing.
This CAD/CAM IPS (In-Plane Switching) monitor from BenQ features a QHD 2560 x 1440 resolution along with a 16:9 widescreen aspect ratio, a 1,000:1 contrast ratio, a brightness rating of 300 cd/m², and a 5 ms response time to provide enhanced picture quality along with reduced ghosting when viewing movies and videos. Setup and configuration is simple as this monitor comes equipped with D-Sub, DVI-DL, DisplayPort 1.2, and HDMI 1.4 input connectors, and both a headphone jack and audio line-in jack. Users can also take advantage of a built-in USB hub to connect USB enabled peripherals directly to the display. Once configured, the IPS panel offers 178° horizontal and vertical viewing angles to see the screen from virtually any angle.
| Weight | 19.95 lbs |
|---|---|
| Dimensions | 26.1 × 19.3 × 7.9 in |
| Size | 23.8" |
| Response Time | 5 ms (GtG) |
| Tilt Adjustment | -5 to 20° |
| Swivel Adjustment | 90° (-45 to 45°) |
| Rotation Adjustment | 90° |
| Height Adjustment | 5.5" / 14 cm |
| Certifications | ENERGY STAR, as per Manufacturer |
| Power Consumption | 0.5 W (Standby)<br />28 W (Typical) |
| Built-In Speakers | Yes, 2 x 1 W |
| Connectivity | 1 x 3.5 mm Input/Output<br />1 x 3.5 mm Output<br />2 x USB Type-A (USB 2.0) Output<br />1 x DVI-D<br />1 x DisplayPort 1.2 Input<br />1 x HDMI 1.4<br />1 x VGA |
| Dot Pitch | 0.205 x 0.205 mm |
| Viewing Angle (H x V) | 178 x 178° |
| Color Gamut | 100% sRGB |
| Screen Area | 20.7 x 11.7" / 52.7 x 29.6 cm |
| Bit Depth / Color Support | 8-Bit (16.7 Million Colors) |
| Variable Refresh Technology | None |
| Dynamic Contrast Ratio | 20, 000, 000:1 |
| Contrast Ratio | 1000:1 |
| Maximum Brightness | 300 cd/m2 |
| Finish | Matte |
| Pixels Per Inch (ppi) | 123 ppi |
| Aspect Ratio | 16:9 |
| Resolution | 2560 x 1440 |
| Touchscreen | No |
| Panel Type | IPS-Type LCD |
| Dimensions (W x H x D) | 22.2 x 20.7 x 9.4" / 563.2 x 524.9 x 239.6 mm (with Stand)<br />22.2 x 13.3 x 2.8" / 563.2 x 338.7 x 71.5 mm (without Stand) |
