The blue 2412 Multi-Conductor – Enhanced Ca 6 Nonbonded-Pair Cable from Belden is a 23 AWG Solid Bare Copper Conductor insulated with polyolefin. It is made up of a PVC (Polyvinyl Chloride) outer jacket and separated internally by dielectric tape. It has a ripcord, which is situated under the jacket of the cable. The cable is suitable for applications such as premises horizontal cable, Gigabit Ethernet, 100BaseTX, 100BaseVG ANYLAN, 155ATM, 622ATM.
| Weight | 25.1 lbs |
|---|---|
| Dimensions | 13.9 × 13 × 11.9 in |
| Pairs | 4 |
| Maximum Capacitance Unbalance | 330 (pF/100 m) |
| Other Specification | Third party verified to Cat 6 |
| Country Patent | US 6570095<br />US 6998537<br />US 7179999<br />US 7977575 |
| Flame Test | UL1666 Vertical riser |
| C(UL) Flame Test | FT4 |
| CSA Flame Test | FT4 |
| Plenum | No |
| Plenum Number | 2413 |
| Nominal Mutual Capacitance | 17.000 capacitance (pF/ft) |
| Nominal Velocity of Propagation | 70 VP (%) |
| MII Order #39 (China RoHS) | Yes |
| Maximum Delay | 537 @ 100 MHz delay (ns/100 m) |
| Max. Delay Skew | 45 delay skew (ns/100 m) |
| Max Conductor DC Resistance | 8.2 DCR @ 68°F (20°C) (Ohm/100 m) |
| Max. Operating Voltage - UL | 300 V RMS |
| Maximum DCR Unbalanced | 5 DCR unbalance @ 68°F (20°C) (%) |
| Storage Temperature Range | 68 to 167°F (-20 to 75°C) |
| Installation Temperature Range | 41 to 122°F (5 to 50°C) |
| Operating Temperature Range | 32 to 167°F (0 to 75°C) |
| Max Recommended Pulling Tension | 40 lb (18.14 kg) |
| Telecommunications Standards | Cat 6 – TIA 568.C.2 |
| CA Prop 65 (CJ for Wire and Cable) | Yes |
| AWG | 23 |
| Overall Cabling Separator Material | Dielectric tape |
| Stranding | Solid |
| Conductor Material | Bare copper |
| Compatibility | Premises horizontal cable, Gigabit Ethernet, 100BaseTX, 100BaseVG ANYLAN, 155ATM, 622ATM |
| Insulation Material | Polyolefin |
| Outer Shield Material | Unshielded |
| Outer Jacket Material | Polyvinyl Chloride |
| Outer Jacket Diameter | 0.22" (0.56 cm) nominal |
| Outer Jacket Ripcord | Yes |
| Overall Nominal Diameter | 0.22" (0.56 cm) |
| EU Directive 2003/11/EC (BFR) | Yes |
| Pair Color Code Chart | White/blue stripe and blueWhite/orange stripe and orangeWhite/green stripe and greenWhite/brown stripe and brown |
| NEC/(UL) Specification | CMR |
| CEC/C(UL) Specification | CMR |
| Other Standards | ISO/IEC 11801 ed 2.1 (2008) Class E |
| EU CE Mark | Yes |
| EU Directive 2000/53/EC (ELV) | Yes |
| EU Directive 2002/95/EC (RoHS) | Yes |
| EU RoHS Compliance Date | 01/01/2004 |
| EU Directive 2002/96/EC (WEEE) | Yes |
| Min. Bend Radius/Minor Axis | 1" (2.54 cm) |
