Description
Expand Your Storage with Areca ARC-4038
The Areca ARC-4038 8-Bay 12Gb SAS Expander JBOD Tower Enclosure is designed to provide a seamless storage expansion solution. With support for up to eight 12 Gb/s SAS or 6 Gb/s SATA drives, this enclosure is perfect for businesses looking to increase their storage capacity.
Key Features:
- Supports up to 8 x 2.5″ or 3.5″ SAS or SATA drives
- 12 Gb/s SAS and 6 Gb/s SATA compatibility
- High-speed drive support: up to 15K RPM for SAS and 10K RPM for SATA
- Plug-and-play configuration for easy setup
- Multiple connectivity options: 4 x SFF-8644 and 1 x SFF-8088 connectors
- Management options: 1 x 6-pin RJ-11 and 1 x RJ-45 LAN connector
This tower enclosure is designed to be user-friendly, with a simple and intuitive design that makes it easy to expand your storage. The ARC-4038 is ideal for businesses that require high-capacity storage solutions, such as data centers, video editing studios, and more.
With its robust design and advanced features, the Areca ARC-4038 8-Bay 12Gb SAS Expander JBOD Tower Enclosure is the perfect solution for businesses looking to expand their storage capacity and improve their data management capabilities.
Additional information
| Weight | 18.1 lbs |
|---|---|
| Dimensions | 15.3 × 13.8 × 7.7 in |
| SAS / SATA Connectivity | SAS hard drives:<br> Up to 8 x 2.5" or 3.5" SAS hot-plug hard drives (12.0 Gb/s) at speeds of 7.2K, 10K or 15K RPM<br><br> SATA hard drives:<br> Up to 8 x 2.5" or 3.5" SATA hot-plug hard drives (6.0 Gb/s) at speeds of 7.2K or 10K RPM |
| JBOD Controller Modules | Expander board: 1 module<br> Sensors: 1 sensor on the expander board |
| Backplane | 8 x SAS hard-drive connectors<br> 1 x power supply connector<br> 2 x cooling fan module connectors<br> 1 x sets of expander board connector |
| Back Panel Connectors | I/O connectors:<br> 2 x SFF-8644 + 1 x SFF-8088 "Host In" connectors for connection to the host<br> 2 x SFF-8644 "Expansion Out" connectors for expansion to an additional JBOD enclosure<br><br> Management connectors:<br> 1 x 6-pin UART RJ-11 connector<br> 1 x RJ-45 LAN connector (manufacture manager only) |
| LED Indicators | Hard-drive carrier:<br> 1 x Blue single-color activity LED<br> 1 x Two-color LED status indicator per drive<br><br> Expander board:<br> 2 x One-color LED status indicators for each SAS host port, one for SAS host port link and one for the activity status<br> 2 x One-color LED status indicators for each SAS expansion port, one for SAS expansion port link and one for the activity state |
| Wattage | 220 W maximum continuous |
| Voltage | 90-256 V rated, 50/60 Hz |
| Amperage | 12 V/16 A, 5 V/16 A, 3.3 V/14 A |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Storage Temperature | -40 to 140°F (-40 to 60°C) |
| Operating Humidity (Relative) | 10 to 80% (non-condensing) |
| Storage Humidity | 5 to 95% (non-condensing) |
